Specifications

• Dimensions

  add remove
  • Length:
    94.9 in (2410 mm) mm
  • Overall width:
    37.2 in (946 mm) mm
  • Seat height, unladen:
    28.3 in (718 mm) mm
  • Seat height:
    26.6 in (675 mm)
  • Ground clearance:
    5.7 in (145 mm) mm
  • Rake:
    26°
  • Trail:
    6.8 in (173 mm) mm
  • Wheelbase:
    64 in (1625 mm) mm
  • Tyres, front specifications:
    130/60B19 M/C 61H
  • Tyres, rear specifications:
    180/55B18 M/C 80H
  • Fuel capacity:
    6 gal (22.7 l) l
  • Oil capacity:
    5 qt (4.7 l) qt.
  • Weight, as shipped:
    802 lb (364 kg) kg
  • Weight, in running order:
    838 lb (380 kg) lb
  • Luggage capacity – volume:
    2.42 cu ft (0.069 m³)
  • Fork angle:
    2.42 cu ft (0.069 m³)
• Engine

  add remove
  • Engine:
    Milwaukee‑Eight® 117 V‑Twin
  • Bore:
    4.075 in × 4.5 in (103.5 × 114.3 mm) mm
  • Displacement:
    1923 cc (117 ci) cm³
  • Compression ratio:
    10.3 : 1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2‑1‑2 dual with tapered mufflers
• Performance

  add remove
  • Horsepower:
    105 hp (78 kW) @ 4,600 rpm
  • Fuel economy:
    44 mpg (5.3 l/100 km) estimated l/100 km
