Specifications

• Dimensions

  add remove
  • Length:
    2410 mm
  • Seat height, unladen:
    720 mm
  • Ground clearance:
    145 mm
  • Rake:
    26
  • Trail:
    173 mm
  • Wheelbase:
    1625 mm
  • Tyres, front specifications:
    130/60B19 M/C 61H
  • Tyres, rear specifications:
    180/55B18 M/C 80H
  • Fuel capacity:
    22.7 l
  • Oil capacity:
    (w/filter) 4.7 qt.
  • Weight, as shipped:
    364 k kg
  • Weight, in running order:
    380.11 kg
  • Luggage capacity – volume:
    0.069 m3
• Engine

  add remove
  • Engine:
    Milwaukee-Eight™ 117
  • Bore:
    103.5 mm
  • Stroke:
    114.3 mm
  • Displacement:
    1923 cm³
  • Compression ratio:
    10.3:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2-1-2 dual exhaust with tapered mufflers
• Performance

  add remove
  • Engine torque testing method:
    EC 134/2014
  • Engine torque:
    175 Nm
  • Engine torque (RPM):
    3500
  • Horsepower:
    107 HP / 80 kW @ 5020 rpm
  • Lean angle, right (deg.):
    32
  • Lean angle, left (deg.):
    32
  • Fuel economy testing method:
    EU 134/2014
  • Fuel economy:
    6 l l/100 km
  • CO₂ emissions testing method:
    EU 134/2014
  • CO₂ emissions:
    143 g/km CO2
• Drivetrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    9.593
  • Gear ratios (overall) 2nd:
    6.65
  • Gear ratios (overall) 3rd:
    4.938
  • Gear ratios (overall) 4th:
    4
  • Gear ratios (overall) 5th:
    3.407
  • Gear Ratios (overall) 6th:
    2.875
• Chassis

  add remove
  • Front fork:
    49 mm Dual Bending Valve
  • Rear shocks:
    76.2 mm Dual Outboard Emulsion with Preload Adjustability
  • Wheels, front type:
    Cast aluminum
  • Wheels, rear type:
    Cast aluminum
  • Brakes, caliper type:
    32 mm, 4-piston fixed dual axially mounted front, and single axially mounted rear
• Electric

  add remove
  • Lights (as per country regulation), Headlamp:
    Signal Lights LED headlamp
  • Lights (as per country regulation), Tail/Stop:
    tail/stop
  • Lights, front signal lights:
    front signal lights
  • Lights, rear turn signals:
    rear turn signals
  • Gauges:
    Digital gauges integrated within the display
• Infotainment

  add remove
  • Infotainment system:
    Skyline™ OS
  • Type:
    Full Color TFT
  • Watts per channel:
    50
  • Speakers:
    2
  • Speaker size:
    Two 5.25 in. fairing speakers
  • AM:
    Standard
  • FM:
    Standard
  • SD Card, Flash Drive and MP3 — via USB Connection:
    Supported
  • Hands-free mobile phone — via Bluetooth:
    Standard
  • Voice recognition: phone functions only:
    Phone dependent
  • Voice Recognition Languages: Tuner / Media / Navigation:
    Embeded on Vehicle
  • Rider / passenger intercom:
    Standard (passenger headset sold separately), VOX is available for HD headsets
  • Bluetooth:
    Phone/Media Player, Headset
