Iron 1200

Description

If you’re looking for a clue on what the new Iron 1200™ is all about, look no further than the name. It all starts with the 1200cc Evolution® engine that gives you loads of famous Sportster® torque. It’s got a throwback look that goes right to the roots of Sportster, thanks to 70’s-inspired tank graphics. You also get a low-slung Café solo seat, mid-mount controls, and mini ape hanger handlebars for an aggressive, two-fists-in-the-wind riding position. Take the power.

Disclaimer: Vehicle shown may vary visually by market and may differ from vehicles manufactured and delivered. Availability may vary by market, please see your local dealer for details.

Specifications

  • Dimensions
    add remove
    • Length
      2200 mm
    • Ground clearance
      110 mm
    • Rake
      30
    • Trail
      117 mm
    • Wheelbase
      1,515 mm
    • Tyres, front specifications
      100/90B19 57H
    • Tyres, rear specifications
      150/80B16 77H
    • Fuel capacity
      12.5 l
    • Oil capacity
      2.6 l
    • Weight, as shipped
      248 kg
    • Weight, in running order
      255.83 kg
  • Engine
    add remove
    • Engine
      Air-cooled, Evolution®
    • Bore
      88.9 mm
    • Stroke
      96.8 mm
    • Displacement
      1,202cc
    • Compression ratio
      10:01
    • Fuel system
      Electronic Sequential Port Fuel Injection (ESPFI)
    • Exhaust
      Black, staggered exhaust and headers with black slash-cut mufflers
  • Performance
    add remove
    • Engine torque testing method
      EC 134/2014
    • Engine torque
      96 Nm
    • Horsepower
      66 HP / x49 Kw @ 6000 rpm
    • Lean angle, right (deg.)
      27
    • Lean angle, left (deg.)
      28
    • Fuel economy testing method
      EU 134/2014
    • Fuel economy
      4.9 l/100 km
    • CO2 emissions testing method
      EU 134/2014
    • CO2 emissions
      120 g/km CO2
  • Drivetrain
    add remove
    • Primary drive
      Chain, 38/57 ratio
    • Gear ratios (overall) 1st
      9.315
    • Gear ratios (overall) 2nd
      6.653
    • Gear ratios (overall) 3rd
      4.948
    • Gear ratios (overall) 4th
      4.102
    • Gear ratios (overall) 5th
      3.517
  • Chassis
    add remove
    • Wheels, front type
      Black, 9-spoke
    • Wheels, rear type
      Black, 9-spoke
    • Brakes, caliper type
      Dual-piston front, Dual-piston rear
  • Electric
    add remove
    • Lights (as per country regulation), indicator
      High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (if equipped), ABS (if equipped)
    • Gauges
      Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights
  • Colour options
    add remove
    • Vivid Black
    • Barracuda Silver
    • Billiard Blue
