Specifications

• Dimensions

  add remove
  • Length:
    2615 mm
  • Seat height, unladen:
    700 mm
  • Ground clearance:
    125 mm
  • Rake:
    26
  • Trail:
    101 mm
  • Wheelbase:
    1670 mm
  • Tyres, front specifications:
    MT 130/60B19 M/C 61H
  • Tyres, rear specifications:
    P215/45R18 83T
  • Fuel capacity:
    22.7 l
  • Oil capacity:
    4.0 l
  • Weight, as shipped:
    488 kg
  • Weight, in running order:
    503.49 kg
  • Luggage capacity – volume:
    2 cu ft (0.09m3 )
  • Tyre, type:
    Dunlop Harley- Davidson Series, bias blackwall front and radial blackwall rear
• Engine

  add remove
  • Engine:
    Milwaukee-Eight® 114
  • Bore:
    102 mm
  • Stroke:
    114 mm
  • Displacement:
    1868 cm³
  • Compression ratio:
    10.5:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    Shorty slash down-style chrome finish mufflers
• Performance

  add remove
  • Engine torque testing method:
    EC 134/2014
  • Engine torque:
    165 Nm
  • Engine torque (RPM):
    2750
  • Horsepower:
    90 HP / 67 kW @ 4750 rpm
  • Fuel economy testing method:
    Estimated City/Hwy
  • Fuel economy:
    43 mpg
• Drivetrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    10.534
  • Gear ratios (overall) 2nd:
    7.302
  • Gear ratios (overall) 3rd:
    5.423
  • Gear ratios (overall) 4th:
    4.392
  • Gear ratios (overall) 5th:
    3.741
  • Gear Ratios (overall) 6th:
    3.157
• Chassis

  add remove
  • Front fork:
    49mm dual bending valve
  • Rear shocks:
    Hand-adjustable emulsion rear suspension
  • Wheels, optional style type:
    Cast aluminum
  • Wheels, front type:
    Cast aluminum
  • Brakes, caliper type:
    Front: 32mm 4 piston fixed, Rear: floating 36mm piston integrated park brake
• Electric

  add remove
  • Lights (as per country regulation), Headlamp:
    Signal Lights+ Dual halogen headlight 55-watt 625 lumen low beam
  • Lights (as per country regulation), Tail/Stop:
    65-watt 1,570 lumen high beam
  • Lights, front signal lights:
    Incandescent tail/stopfront signal lights and rear turn signals
